Focused Ion Beam Systems

Advanced SEM anaylsis, FIB slice&view and TEM sample preparation

The FEI Strata 400S and the Zeiss Auriga 60 Dual Beam FIB are both a combination of a scanning electron microscope (SEM) and a focused ion beam (FIB) system, which allows imaging and structuring of materials at the nanoscale. The focused gallium ion beam can either be used for ion imaging or to cut predefined patterns or images in the surface of a solid. At the same time, the SEM can be used to image the nanostructures generated by FIB. In addition, it is possible to locally deposit C, Pt or W from precursor gases using the electron or ion beam. Additionally, Insulator Enhanced Etching (IEE) using XeF2 is available.

Zeiss Auriga 60
Zeiss Auriga 60

DualBeam FIB with EDX, EBSD and vacuum transfer system

link
FEI Strata 400
FEI Strata 400

DualBeam FIB with EDX
